Product Details:
Place of Origin: China
Brand Name: Chenguang
Certification: CE SGS
Model Number: ZPS15
Payment & Shipping Terms:
Price: Negotiable
Packaging Details: Metal frame with poly-wood package
Delivery Time: 30DAYS
Payment Terms: L/C, T/T, D/P, Western Union
Contact Now
Detailed Product Description
Application: Tablet Production Name: Pill Compressor Machine
Condition: New Max Pressure: 150kn
High Light:

rotary tablet compression machine


single punch tablet machine


Stable Performance Pill Compressor Machine


Machine introduction:

The machine is a double-pressing automatically revolving piece-pressing machine which could make grain be pressed to be round piece, be carved characters, special shapes and double color piece prescription. It is mainly used in manufacturing piece prescription for pharmaceutical industry and industry enterprises like chemical industry, foods, electronics. (Note:when manufacturing double color piece, if only need replacing components and adding powder absorbing apparatus which greatly lowers the cost and raises profit.)

1. The cover is made of stainless steel with close type. The inner table surface is also applied with stainless steel materials which could keep surface luster and prevent from being pol luted crossly, comply with GMP requirement.
2. Equipped with plexiglass perspective window which could help to observe the status of pressing piece. Side blank could be fully opened, easy to clean and maintain.
3. All monitors and operating components are in good order.
4. Applying with frequency changing , speed regulating apparatus to be electricity regulation. The convenient operation and smooth revolving are safe and correct.
5. Equipped with over-load protection apparatus. When pressure overloads, the machine will stop automatically.
6.The first of its kind to use semi-automatically lubricating equipment and plexiglass anti-dust cover on the upper of revolving table.
7.Ransmitting system is sealed in the oil box under the main machine which is a separate component. No pollution and easy to send out heat and resist grinding.
8. Powder-absorbing apparatus could absorb the powder in the piece-pressing room.


Machine specification:


Model ZPS15
Dies(sets) 15
Max pressure(KN) 150
Max.dia.of tablet(mm) 35
Max.depth of fill(mm) 36
Max.thickness of tablet(mm) 12
Max.production capacity(pc/h) 36000
Turret speed(r/min) 0-20
Motor QA112M4A. 7.5KW
960r/min 380v. 50Hz
Overall size(mm) 1400*1200*1800
Weight 2500
